A-QDM6P — Light Fixture Stair Detail

Architectural · A-QDM6P

Light Fixture Stair Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A-562
Discipline: Architectural

Materials

Gypsum / Drywall Metal (misc.)

Elements

Ceilings Stairs

Text on the drawing

32° GYPSUM BOARD CEILING LIGHT FIXTURE. SEE REFLECTED CEILING PLAN FOR LOCATION. COORDINATE LOCATION WITH ARCHITECT AND ELECTRICAL METAL PAN STAIR
