An HSS stair stringer terminates at a concrete beam and connects via a one-half-inch thick end plate. A steel railing assembly mounts to the stair structure, featuring one-and-a-half-inch outside diameter steel pipe posts and a matching handrail supported by one-half-inch steel flat bars. Pickets maintain a spacing of less than four inches typically. The top of the railing is set at three feet six inches above the landing, with the handrail positioned at three feet zero inches.
TOP OF HANDRAIL 3'-0" TOP OF RAILING 3'-6" 1 1/2" O.D. STEEL PIPE HANDRAIL 1/2" STEEL FLAT BAR HANDRAIL SUPPORT 1 1/2" O.D. STEEL PIPE AS POST HSS STAIR STRINGER STAIR 9 A7.20 4" 1/2" THICK END PLATE MIN. 1" 4" TYP. LESS THAN 1'-7 1/4" 1" MIN. 12" 7 1/2" CONC BEAM S.S.D.
