Configuration for clean air vanpool and electric vehicle parking stalls including back-to-back parking arrangements and landscape interfaces. The assembly consists of asphalt paving with a three-inch thickness adjacent to an eighteen-inch concrete gutter and a concrete curb or wheel stop as required. Traffic paint striping utilizes three-inch wide white lines marked along the center line of the parking aisle. Stall dimensions and vehicle overhangs are referenced to the primary site plan.
LANDSCAPE PARKING AT PARKING BACK TO BACK OCCURS WHEEL STOP AS CONC. CURB OR STRIPING TRAFFIC PAINT 3" WIDE WHITE OF PARKING CENTER AISLE CENTER LINE @ 18" @ CONC. GUTTER 3" @ ASPHALT OVERHANG DIMENSION SEE SITE PLAN FOR SEE SITE PLAN FOR PARKING STALL DIMENSIONS VEHICLE VANPOOL/EV CLEAN AIR
