The dimension point of the curtain wall mullion is set at an angle of 120.96 degrees relative to the framing members. The distance from the face of glass to the edge of the slab measures seven and one-quarter inches, with an additional four and one-quarter inches to the centerline of the mullion. A dimension range of three and three-eighths inches minimum to one foot maximum is specified for the fin information. Reference sheets A364 through A373 for additional fin details.
DIM PT OF MULLION F O G 7 1 / 4 " EDGE OF SLAB CURTAIN WALL 4 1 / 4 " 3 1 / 4 " 1 2 0 . 9 6 ° R E : A 3 6 4 - A 3 7 3 F O R F I N I N F O R M A T I O N 3 3 / 8 " ( M I N ) - 1 ' - 0 " ( M A X )
