Handrail is anchored to the wall using support brackets spaced to handle structural loads at a maximum of 5 feet on center. All rail intersections feature radiused corners and return directly to the wall. The ramp itself is set to a 1:12 slope with the railing positioned 3 feet above the finished surface.
1:12 SLOPE 3' - 0" END OF RAMP 3' - 0" LOCATE BRACKETS AT SPACING REQUIRED TO SUPPORT STRUCTURAL LOADS NOT TO EXCEED 5' - 0" OC NOTE: ALL RAIL INTERSECTIONS TO BE RADIUSED (TYP) AND RETURNED TO WALL 1' - 0" 1' - 0"
