Architectural · A-Q9PCH

Portal Jamb Concession Signage Ledge Detail

Materials

Steel Timber / Wood Masonry / CMU Metal (misc.)

Elements

About this detail

Metal framing supports an 8-inch steel plate signage ledge above, anchored with two-inch metal strapping spaced at 16 inches on center. Countersunk screws, painted to match metal plate MT25, secure the assembly and align with the header above. A thinset mortar bed applies over the backing to receive scheduled tile finishes. Metal framing, drywall, and finishes are provided by the tenant.
