The assembly features a curtain wall head condition terminating below a soffit finished with perforated metal panels and starter metal furing with a cleat. Continuous twenty-two gauge metal flashing and drip edge match the metal panel finish and integrate with continuous backer rod and sealant. An air barrier extends into the head assembly above the curtain wall frame, with shims placed for alignment. Metal jambs are visible beyond the primary frame section.
STARTER METAL FURING W/ CLEAT E-2 / A310 PERFORATED METAL PANEL - PAINTED CURTAIN WALL CONT. BACKER ROD & SEALANT SHIM INSTALL AIR BARRIER INTO HEAD 6" 8" 19" 8" 6" 3" CONT. 22 GA. METAL FLASHING AND DRIP EDGE, TO MATCH METAL PANEL METAL JAMB BEYOND
