This roof overhang detail shows the parapet extending to an elevation of 37'-10" above the bottom of the outer beam at 35'-3". The roof deck bears at 36'-3" while the top of the curtain wall is set at 35'-0". The assembly coordinates structural steel framing with exterior cladding and parapet waterproofing.
PARAPET 2 37'- 10" A B.O. OUTER BEAM 35'- 3" T.O. CW 35' -0" B.O. ROOF DECK 1 36'- 3"
