A structural steel column connects to beams per plan using a 1-inch thick base plate with machined scribe lines on top measuring 1/16-inch wide by 1/32-inch deep. Four 13/16-inch by 1-inch slotted holes provide adjustability for the connection. The bottom surface of the base plate features a TSC finish.
X 11 PL 1" x AS SHOWN BEAM PER PLAN BEAM PER PLAN COLUMN PER PLAN 3" 5" 5" 4" 4" 1/2" 4 PLCS 13/16" x 1" SLOTTED HOLES MACHINE SCRIBE LINES ON TOP OF PLATE AS SHOWN, 1/16" WIDE x 1/32" DEEP TSC BOTTOM SURFACE OF BASE PL 1 1/2"
