Galvanized Steel Pipe Handrail and Toeboard at Grating Edge

Materials

Elements

About this detail

A 1-1/2 inch schedule 40 galvanized steel pipe top rail and vertical post connect to a structural steel support at the grating edge. Posts are spaced at a maximum of 4 feet on center. A 1/4 inch by 4 inch galvanized steel flat bar toeboard is attached at the base, positioned 1 foot 9 inches above the top of the grating level. Galvanized steel grating bears on the structural framing as specified per structural drawings.
