This interior detail shows a recessed roller shade assembly integrated into a framed ceiling pocket. The shade bracket secures the roller tube and shade band assembly within the pocket, which features a single closure mount and a removable closure piece. The shadecloth drops down through the slot, terminating in a hembar sealed inside the fabric. Dimensional clearances of two and three-eighths inches, two inches, three inches, and five inches coordinate the pocket geometry with the surrounding construction.
CEILING HEIGHT AS SCHEDULED SINGLE CLOSURE MOUNT HEMBAR SEALED INSIDE SHADECLOTH ROLLER TUBE AND SHADE BAND ASSEMBLY REMOVABLE CLOSURE SHADECLOTH BRACKET 2 3/8" 1/4" 2" 3" 5" 2" 5" 4
