This double stud partition wall is framed with six-inch metal studs spaced across a one-foot six-inch air space. Sound attenuation batt insulation fills the stud cavities for acoustic control. Each side of the partition is finished with one-half-inch backer board and a wall finish determined per the finish schedule.
OVERALL DIM. 2' - 7" 6'' METAL STUDS, SEE S.S.D. SOUND ATTENUATION BATT INSULATION 1/2" BACKER BOARD, EACH SIDE, SEE INTERIOR ELEVATION AND FINISH SCHED. FOR FINISHES AIR SPACE 1' - 6" WALL FINISH, SEE FINISH SCHEDULE
