A steel column with spray-on fireproofing sits within an exterior wall corner. EIFS-1A cladding applies over insulation. The enclosure layout dimensions are 10 1/2 inches and 1 foot 7 1/4 inches from building grid lines. Refer to structural drawings for steel column fireproofing specifications.
