Suspended acoustical ceiling systems require seismic bracing with a compression strut spaced at twelve feet on center maximum. The strut is sized using electrical metallic tubing ranging from one-half inch up to five-foot spans, three-quarters inch up to eight-foot spans, and one inch up to ten-foot spans. An angle clip pinned to the ceiling structure with a Hilti fastener secures the top of the compression strut. Pairs of twelve-gauge splay wires at forty-five degrees run parallel to both main tees and cross tees. Twelve-gauge hanger wires are set in the concrete slab within a conduit and spaced at four feet on center maximum.
TYP. 12GA. HANGER WIRE SET IN CONC. SLAB WITHIN CONDUIT 2-12GA SPLAY WIRES AT 45° PARALLEL TO CROSS TEES ANGLE CLIP. PINNED TO CEILING STRUCTURE HILTI CC27xALH37, TYP. COMPRESSION STRUT @ 12'-0" O.C. MAX 1/2" EMT - UP TO 5'-0" 3/4" EMT - UP TO 8'-0" 1" EMT - UP TO 10'-0" 2-12GA SPLAY WIRES AT 45° PARALLEL TO MAIN TEES LOCKING CROSS TEES @4'-0" O.C., TYP. MAIN TESS @4'-0" O.C. TYP. HANGER WIRES @4'-0" O.C. 2" MAX 2" MAX
