The membrane roofing system end lap detail shows overlapping layers secured with mechanical fasteners and fastening plates spaced approximately five and one-half inches apart. A hot air weld joins the membrane sheets with a minimum one and one-half inch overlap. Edge sealant is applied along the perimeter per note three.
1 1/2" MIN 5 1/2" APPROXIMATELY 1/2" 1 1/2" MIN MEMBRANE ROOFING SYSTEM END LAP DETAIL LAP DETAIL FASTENER and FASTENING PLATE HOT AIR WELD EDGE SEALANT, REFER TO NOTE #3 MEMBRANE ROOFING SYSTEM HOT AIR WELD EDGE SEALANT, REFER TO NOTE #3
