Two number four reinforcing bars, three feet long, are placed diagonally in the upper third of the slab at all re-entrant corners typically. The slab on grade features a building corner or construction joint at the inside angle.
3'-0" 2 #4 BARS 3'-0" LONG (UPPER 1/3 OF SLAB) AT ALL RE-ENTRANT CORNERS (TYP.) SLAB ON GRADE BUILDING CORNER OR CONSTRUCTION JOINT TYPICAL RE-ENTRANT CORNER 3
