An elevator hall station features a one-eighth-inch thick brushed stainless steel panel with vertical grain and black etched and filled graphics, mounted at three feet six inches above finished floor to center. The assembly includes up and down call buttons with square shoulders and tactile raised profiles that illuminate with white light. First floor installations incorporate additional black engraved text, a fire department operation key switch for elevator recall, and a firefighters phone jack. Regulatory compliance notes specify mechanical motion activation and visible signal requirements in accordance with accessibility standards.
IN CASE OF FIRE, USE STAIRWAYS FOR EXIT. DO NOT USE ELEVATOR FIREFIGHTERS' OPERATION 3' - 6" A.F.F. NOTES: 1. 1/8" THICK BRUSHED STAINLESS PANE (VERTICAL GRAIN) WITH ETCHED AND FILLED GRAPHICS (BLACK) 2. CALL BUTTONS SHALL HAVE SQUARE SHOULDERS, BE 3/4" MINIMUM IN THE SMALLEST DIMENSION AND SHALL BE RAISED 1/8" PLUS OR MINUS 1/32" ABOVE THE SURROUNDING SURFACE. THE BUTTON SHALL BE ACTIVATED BY A MECHANICAL MOTION THAT IS DETECTABLE PER CBC 11B-407.2.1.2. 3. CALL BUTTONS SHALL HAVE VISIBLE SIGNALS THAT ACTIVATE WHEN EACH CALL IS REGISTERED AND EXTINGUISH WHEN EACH CALL IS ANSWERED PER CBC 11B-407.2.1.5. BLACK ENGRAVED TEXT OVER VERTICAL GRAIN STAINLESS STEEL UP BUTTON ARROW (NOT AT TOP FLOOR) - ENTIRE BUTTON TO BE ILLUMINATED WITH WHITE LIGHT DOWN BUTTON (NOT AT FIRST FLOOR) - ENTIRE BUTTON TO BE ILLUMINATED WITH WHITE LIGHT BLACK ENGRAVED TEXT OVER VERTICAL GRAIN STAINLESS STEEL TO BE APPLIED AT FIRST FLOOR ONLY FIRE DEPT. OPERATION KEY TO BE APPLIED AT FIRST FLOOR ONLY FIREFIGHTERS' PHONE JACK TO BE APPLIED AT FIRST FLOOR ONLY To recall elevators Insert fire key and turn to "ON" FIRE RECALL
