A-PYMKT — Lateral Line Trenching

Architectural · A-PYMKT

Lateral Line Trenching

Units: imperial
Sheet: RA-L4.2.1
Discipline: Architectural

Elements

Text on the drawing

BACKFILL W/ APPROVED EXCAVATED MATERIAL NOT TAPE BUNDLED WIRES TO MAIN LINE FINISH GRADE TRACER WIRE BACKFILL W/ APPROVED EXCAVATED MATERIAL SCH 40 PVC LATERAL LINE PIPE BEDDING COMPACTED SUBGRADE 1' 3' 6" 2" NOTE: DRIP LINES HAVE THE OPTION TO BE TURNED OFF AFTER ESTABLISHMENT OF PLANT MATERIAL. LATERAL LINES FOR ROTORS WILL BE INSTALLED ABOVE GROUND ON STAKED PVC LINES, LIGHTLY COVERED WITH MULCH.
