The door frame head sits within a concrete wall opening, with the frame profile positioned to accommodate a 5/8 inch thick finish material. Sealant is applied to both the interior and exterior sides at the junction with the wall. A shim space is provided at the head, with the frame width varying per the manufacturer's specifications. The assembly includes specific material references for the wall substrate, frame, and finish layers.
