Architectural · A-PY2HG

Ceiling Edge Condition at Sloping Stud Wall

Materials

Concrete Steel Timber / Wood Metal (misc.)Gypsum / Drywall

Elements

Beams Walls Ceilings Floors / Slabs Decks Bracing Connections / Plates

Connections

Bracing Connection

About this detail

A linear wood ceiling and a stretched fabric ceiling system meet a vertical sloping stud wall and a concrete floor slab on metal deck at the ceiling edge condition. The assembly features a structural steel beam protected by spray fireproofing beneath the concrete slab, with continuous gypsum board finished in paint PNT-1 running down the face. The stretched fabric ceiling system utilizes Unistrut framing secured with a Barrisol BS350 edge clip and a one-quarter-inch metal plate. A note specifies that all interior areas above the linear wood ceiling must be painted PNT-13, including the structure, mechanical, electrical, plumbing, fire protection, and underside of the slab.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
