A-PX4GP — Saddle Ridge Detail

Architectural · A-PX4GP

Saddle Ridge Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A-508
Discipline: Architectural

Materials

Gypsum / Drywall Stainless Steel Steel Stone Timber / Wood

Elements

Beams Decks Insulation Roofs Waterproofing / Flashing

Text on the drawing

G RIDGE BEAM RE: STRUCTURAL STEEL ROOF FRAMING RE: STRUCTURAL ROOF DECKING RE: STRUCTURAL 6" RIGID ROOF INSULATION FIRE-RETARDANT- TREATED PLYWOOD ROOF SHEATHING ROOF UNDERLAYMENT SLATE SHINGLES SELF-ADHERED SHEET UNDERLAYMENT WOOD NAILERS STAINLESS STEEL RIDGE FLASHING INTERWOVEN WITH EACH PAIR OF RIDGE SLATES RIDGE SLATES 5/6" GYPSUM SHEATHING VAPOR BARRIER
