A-PX2S5 — Typ. 1hr Rated Steel Column Wrap Detail

Architectural · A-PX2S5

Typ. 1hr Rated Steel Column Wrap Detail

Units: metric
Sheet: A-MB-8.10
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Steel Timber / Wood

Elements

Connections

Text on the drawing

HSS COLUMN REFER TO STRUCTURAL DWGS 42mm STEEL STUD 2 x 16mm TYPE X GYPSUM BOARD 42mm STEEL STUD 2 x 16mm TYPE X GYPSUM BOARD TYP. 1HR RATED STEEL COLUMN WRAP DETAIL
