An elevator door threshold sits flush against the finish floor as scheduled. A steel angle supports the threshold assembly at the edge of the floor structure. The steel angle is secured to the floor structure using expansion bolts.
ELEVATOR DOOR THRESHOLD FINISH FLOOR AS SCHEDULED EXPANSION BOLT STEEL ANGLE FLOOR STRUCTURE
