A structural steel equipment curb mounts directly to existing roof structure and is secured with two-by-two angles screwed around the perimeter. A curb perimeter assembly receives a top cap that is tack welded onto the curb. A high hat section is positioned across the top and tack welded onto the cap. Surrounding roof insulation, wood nailers, roof membrane, and flashing are provided by others.
WOOD NAILER ROOF INSULATION (BY OTHERS) ROOF MEMBRANE (BY OTHERS) CAP TO BE TACK WELDED ONTO THE CURB CURB PERIMETER EXISTING STRUCTURE (BY OTHERS) HIGH HAT TO BE TACK WELDED ONTO THE CAP FLASHING (BY OTHERS) 2" x 2" ANGLE SCREWED TO STRUCTURE AROUND PERIMETER OF CURB
