An interior light-gauge steel stud wall terminates at a mass timber wood beam, utilizing light-gauge steel deflection tracks at the top of the wall for structural separation. A reglet designated as DRMF-625-50 interfaces with the painted gypsum board finish. A site-specific dimensioned closure plate provides finishing concealment at the beam intersection.
reglet "DRMF-625-50" wd. beam, s.s.d. gyp. bd., ptd. closure plate, s.s.d. provide LGS deflec Ɵon tracks at top of wall to mass Ɵmber con nec Ɵon, typ. fl-02 01
