A closure angle is positioned at the edge of the composite deck, bearing on a wide-flange steel beam protected by spray fireproofing and a sheet metal extension. The shaft wall assembly maintains a 1-3/4 inch dimension from the framing line, with a zero-inch offset condition specified where the brace frame does not exist. A brace frame element is located above the deck level relative to the shaft wall alignment.
1 31/32" 0" WHERE BRACE FRAME DOES NOT EXIST 7" SHAFT WALL ASSEMBLY SHEET METAL EXTENSION SPRAY FIRE PROOFING BRACE FRAME SHAFT WALL ASSEMBLY 1'-3" COMPOSITE DECK CLOSURE ANGLE
