A single-ply roofing membrane is installed over a two-layer polyisocyanurate insulation system supported by a steel deck. The bottom layer of polyisocyanurate insulation is mechanically fastened to the steel deck per the manufacturer recommendations to meet Factory Mutual Class 1 guidelines. The second layer of polyisocyanurate insulation is fully adhered to the first layer with insulation board joints offset a minimum of 18 inches. The single-ply roofing membrane features lap splices and seam edge treatments installed per the manufacturer specifications.
SEE SPECIFICATIONS FOR APPROVED SINGLE-PLY ROOFING SYSTEMS LAP SPLICE, INSTALL PER ROOFING MANUFACTURER'S SPECIFICATIONS. SEAM EDGE TREATMENT PER ROOFING MANUFACTURER'S SPECIFICATIONS SINGLE-PLY ROOFING MEMBRANE SECOND LAYER OF POLY- ISOCYANURATE TO BE FULLY ADHERED TO FIRST LAYER. INSULATION BOARD JOINTS TO BE OFFSET MINIMUM OF 18" FIRST LAYER OF POLY- ISOCYANURATE INSULATION TO BE MECHANICALLY FASTENED PER ROOFING SYSTEM MANUFACTURER'S RECOMMENDATIONS TO MEET FACTORY MUTUAL CLASS 1 GUIDELINES STEEL DECK MIN. 2 1/4" 1 1/2"
