An interior between-glass venetian blind assembly is mounted within a two-inch profile frame utilizing removable stops on both sides for maintenance access. A blind tilt control mechanism extends through the frame housing as indicated. Dimensions and equal spacings are provided as required to locate the profile components.
5/8" 2" 2" 1/2" 1/2" REMOVABLE STOP (BOTH SIDES) BLIND TILT CONTROL "X" WINDOW - BETWEEN GLASS VENETIAN BLIND F8 AS REQD AS REQD EQ EQ
