Architectural · A-PQYCE

Window Head Jamb Detail at Steel Beam and Stucco Wall

Materials

Steel Timber / Wood Metal (misc.)Gypsum / Drywall EIFS / Plaster / Stucco

Elements

Columns Beams Windows Ceilings Anchors / Embeds

Connections

Welded Connection

About this detail

An overhead steel beam and structural column beyond provide the primary anchorage for a window head jamb assembly. A welded threaded stud with countersunk fasteners secures wood framing including a two-by wood nailer and a four-by wood header. An EFCO window frame attaches below using typical EF, F, or M clips and is sealed with typical sealant and backer rod. Interior finishes feature five-eighths inch gypsum wallboard, while the exterior layers comprise a metal soffit vent, one-half inch sheathing, a vapor retarder, and a three-coat stucco finish. A roller shade and guide assembly is integrated into the head framing adjacent to the window.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
