Fabricator is required to submit a full scale sample in entirety as specified to A&E and SMA design. The sign dimensions are one foot two inches wide by eleven inches high.
R e o m t s r o 11 FABRICATOR TO SUBMIT A FULL SCALE SAMPLE IN ENTIRETY AS SPECIFIED TO A&E + SMA DESIGN 11" 1'-2"
