A-PMXYY — Elevator Shaft at Floor

Architectural · A-PMXYY

Elevator Shaft at Floor

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Elements

Beams Ceilings Decks Floors / Slabs Partitions Walls

Text on the drawing

INTERIOR WALL ASSEMBLY RE: FLOOR PLANS LEVEL 1 100'-0" STRUCTURAL BEAM, RE: STRUCTURAL DRAWINGS SUSPENDED CONCRETE DECK, RE: STRUCTURAL DRAWINGS SCHEDULED CEILING RE: REFLECTED CEILING PLANS FIRE SEALANT FIRE-RATED WALL ASSEMBLY RE: FLOOR PLANS INTERIOR WALL ASSEMBLY RE: FLOOR PLANS SHAFT

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
