Two 3-5/8 inch 20 gauge cold-formed metal studs with 2-1/2 inch legs are nested together to form a structural strongback assembly. The studs are fastened together using number 10 sheet metal screws spaced at 12 inches on center.
3 5/8", 20 GA METAL STUDS W/ 2 1/2" LEG #10 SHEET METAL SCREWS @12" OC SECTION A-A 3 5/8", 20 GA METAL STUD STRONGBACK W/ 2 1/2" LEG
