A-PHYX9 — Louver In Precast

Architectural · A-PHYX9

Louver In Precast

Units: metric
Sheet: A366
Discipline: Architectural

Materials

Aluminum Concrete Steel

Elements

Connections / Plates Facades / Cladding Roof / Floor Openings Walls Waterproofing / Flashing

Connections

Welded Connection

Text on the drawing

BASIS OF DESIGN: EME6625D BY RUSKIN CONT SEALANT ALL AROUND 1-3/4x 3x 3/16 ALUM ALUM ATTACHMENT ANGLE FACTORY WELD TO CHANNEL. JAMB LJ2
