A two-foot-two-inch low wall flanks the stairs, finished with a sloped painted wood cap at the top. The wall surface is covered with wall carpet and features an aisle light coordinated with the mechanical and electrical plans. Stair treads include a two-inch alternate colored lighting strip at the top and bottom nosing edges. The base of the assembly incorporates a rubber base notched to fit at the flooring transition strip along the edge of the riser.
RUBBER BASE NOTCHED TO FIT AT FLOORING TRANSITION STRIP EDGE OF RISER RUBBER BASE FLOORING TRANSITION STRIP 2" ALTERNATE COLORED LIGHTING AT TOP AND BOTTOM TREAD NOSING EDGE, TYP. AISLE LIGHT, SEE MEP PAINTED WOOD CAP 2'-2" LOW WALL WITH SLOPED TOP CAP WALL CARPET CORNER GUARD
