A tilt-up concrete wall assembly features a continuous sealant bead at the exterior joint and a shim space provided as needed for alignment. Dimensional clearances of three-quarters of an inch and two inches govern the joint spacing and panel placement.
SHIM SPACE IF NEEDED TILT-UP CONCRETE WALL CONT. SEALANT BEAD 3/4" 2"
