The stair stringer bears directly onto the concrete slab and is anchored according to typical detail specifications. Stair treads feature an eleven-inch run dimension and are supported by steel channels sized per plan. A wall-mounted handrail is secured to drywall and internal blocking.
HANDRAIL, SEE FASTEN TO DRYWALL/ BLOCKING / 11 A7.10 CHANNEL PER PLAN SEE FOR TYP. STRINGER AT SLAB / 14 A7.10 11"
