Plastic-laminate-faced architectural cabinet mounted to wall. Cabinet interior features melamine-faced substrate with adjustable plastic-laminate-faced standards and supports for shelving. Scheduled pull mounted to cabinet door. Cabinet depth sized per plan; vertical height sized per elevation.
