Text on the drawing
WINDOW SCHEDULE FINISH HEAD JAMB SILL GLAZING HEAD HEIGHT COMMENTS THICK TYPE 74' - 4" TYPICAL OF PANELS IN HANGAR DOORS WH1 WJ1 WS1 8' - 8" WH1 WJ1 WS1 8' - 8" WH1 WJ1 WS1 8' - 8" WH1 WJ1 WS1 8' - 8" WH5 WJ5 WS5 8' - 8" WH1 WJ1 WS1 8' - 8" WH1 WJ1 WS1 8' - 8" RIBBON WINDOW RIBBON WINDOW RIBBON WINDOW RIBBON WINDOW RIBBON WINDOW RIBBON WINDOW RIBBON WINDOW DAYLIGHT PANEL
