Jamb connection for a hollow metal door frame set into a metal stud partition. King studs flank the opening with a metal track header, tied to the frame using three Z-anchors per jamb. A one-quarter-inch shim space is maintained at the rough opening, finished with a J-mold on both sides. The hollow metal frame is filled with acoustical insulation when installed in an acoustic partition. A concealed hinge connects the door leaf to the frame, with the jamb width matched to the overall wall width.
PER PLAN PARTITION MATCH WALL WIDTH JAMB WIDTH TO DOOR WIDTH PER SCHEDULE METAL TRACK KING STUDS FINISH WHERE OCCURS, TYP. BOTH SIDES "Z" JAMB ANCHOR - 3 PER JAMB HOLLOW METAL DOOR FRAME FILL W/ ACOUSTICAL INSULATION WHERE INSTALLED IN ACOUSTIC PARTITION, TYP. DOOR PER SCHEDULE DOOR FRAME BEYOND CONCEALED HINGE ALIGN BOTH SIDES "J" MOLD 2" 1/4" SHIM SPACE
