An exterior concrete sidewalk is sloped two percent away from the building, aligning with the face of the vertical construction board beyond. A waterproofing membrane laps up under the threshold and seals against the wall beyond. A continuous one-quarter-inch bead of joint sealant is applied per the manufacturer instructions. The threshold assembly anchors to the concrete substrate alongside wood flooring assemblies and framing components.
CONC. SIDEWALK SLOPED 2% AWAY FROM BUILDING SEE CIVIL DWGS. 079200.JS LAP UP UNDER THRESHOLD AND SEAL. LAP UP WALL BEYOND 072727.ROF 084113.ED 079200.JS SWEEP/SEAL 033000.JF 1/4" CONT. BEAD 072727.ROF BEYOND PER MFR 1 1/2" ALIGN W/ FACE OF VCB 4" 6" 5" 6" WALL BEYOND 096466.WAF 084113.T 084113.T 084113.T
