A curved access door is constructed with an HSS 2 1/2 x 2 x 1/4 hollow structural section frame formed to match the radius of the adjacent metal mesh enclosure. The door assembly measures 3 feet 5 inches wide by 6 feet 8 inches high with a 4 inch clearance above the finished floor. A 3/4 inch diameter locking cane bolt secures the door at the base. The frame is anchored adjacent to concrete construction.
HSS 2 1/2X2X1/4 FRAME, TO MATCH RADIUS OF METAL MESH 4" 6' - 8" 4 1/2" 3' - 5" 3/4" DIA LOCKING CANE BOLT 16 A5.08 1/2" = 1'-0" A2.13 2 HELIX ACCESS DOOR
