The raised platform consists of luxury vinyl tile flooring over double three-quarter-inch plywood layers and two-by wood sleepers spaced twelve inches on center. A hardwood bullnose edge detail features an LVT-20 nosing piece with an inset aluminum track and internal LED light tape. An adjoining half-inch plywood panel extends down the platform face toward the finished floor below. A note specifies that the platform must remain unattached to the structural floor.
LVT FLOORING OVER (2) 3/4" PLYWOOD, 2x SLEEPERS AND ADDITIONAL PLYWOOD AS REQUIRED BY FRAMING CONTRACTOR LVT-20 NOSING AT BULL NOSE OVER HARDWOOD BY MILLWORK SEE PLAN FOR FLOOR FINISH 2x WOOD SLEEPERS AT 12" OC ALUMINUM TRACK WITH INTERNAL LED LIGHT TAPE - COORDINATE INSTALLATION WITH FRAMER, FLOORING AND LOW VOLTAGE CONTRACTORS SEE TECHNOLOGY AND ELECTRICAL EXTRUDED LIGHTING NOTE: PLATFORM SHALL NOT BE ATTACHED TO FLOOR 1/2" PLYWOOD MAX 7" 1" 1" 2" 4"
