A solid wood base with a reveal is installed flush with the outer layer of gypsum board wall finish. An L-bead edge trim finishes the drywall transition directly above the wood base reveal. Sheet metal backing is installed where single-layer gypsum board is used at scheduled partitions.
REFER TO PARTITION TYPES OUTER LAYER OF GYPSUM BOARD w/ SCHEDULED FINISH SOLID WOOD BASE w/ REVEAL. FINISH PER SCHEDULE REFER TO FINISH PLAN SHEET METAL WHERE ONE LAYER OF GYPSUM BD @ SCHEDULED PARTITION ALIGN SEE SCHEDULE EDGE TRIM, L-BEAD
