A-P373E — Guardrail & Fin Attachment - 2Nd Floor - D

Architectural · A-P373E

Guardrail & Fin Attachment - 2Nd Floor - D

Units: imperial
Sheet: A-PK-8.01
Discipline: Architectural

Materials

Elements

Connections / Plates Facades / Cladding Floors / Slabs Railings / Guards

Text on the drawing

2F03-C TO PK GROUND LEVEL 9144 [30'] PERFORATED PANEL DIVIDED INTO 3-3048 [10'] X 800 mm PANELS BOTTOM OF FIN PRE-FABRICATED 76.2mm X 5mm FLAT METAL FRAMING FASTENED TO 2-100mm X 6mm VERTICAL METAL STANCHIONS 2-100mm X 6mm VERTICAL METAL STANCHIONS STRUCTURAL METAL FRAMING 9144 [30'] DIVIDED INTO 3-3048[10'] PANELS 4146mm TO FFL

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
