A-NZEWX — Drinking Fountain

Architectural · A-NZEWX

Drinking Fountain

About this detail

This elevation and plan detail specifies the installation dimensions and required clear floor space for an accessible drinking fountain. The spout is positioned at a maximum height of 36 inches, with a knee clearance height of 27 inches minimum. A clear floor space measuring 30 inches minimum by 48 inches minimum is provided in front of the fixture.

CLR. FLR. SPACE DRINKING FOUNTAIN (ELEVATION) DRINKING FOUNTAIN (PLAN) 24" MAX. 30" MIN. 48" MIN. 17"-19" SPOUT MAX. 36" T.O. 27" MIN. 6" MAX. MIN. 8 1/4" 9" MIN.
