Maximum forward reach dimensions apply for a wheelchair user facing a wall-mounted element or fixture. A vertical dimension limit of 48 inches maximum is measured from the finished floor to the highest operable part or reach point. A horizontal obstruction depth of 20 inches maximum limits the reach over a counter or obstacle extending from the wall.
