Architectural · A-NYAAG

Section

Scale: SCALE: 1/4" = 1'-0"
Units: imperial
Sheet: A455
Discipline: Architectural

Materials

Glass / Glazing

Elements

Columns Stairs Waterproofing / Flashing

Text on the drawing

LEVEL TN -11' - 8" B.23 (14) EQUAL RISERS 8' - 0" TUNNEL 2' - 0" A503 5 SIM COL WATERPROOFING
