A-NXBSX — Stair 3 - Longitudinal Section

Architectural · A-NXBSX

Stair 3 - Longitudinal Section

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Discipline: Architectural

Materials

Elements

Floors / Slabs Railings / Guards Stairs

About this detail

A cast-in-place concrete stair assembly features a standard tread and riser configuration. The concrete slab rests on an underlying steel structure. A dashed boundary box identifies a specific connection or condition referenced by detail callout 69 on sheet A6.2.4.

Text on the drawing

A6.2.4 69
