This partition intersection consists of a primary wall meeting a perpendicular wall, both framed with metal studs. Each side of the wall assembly is finished with two layers of five-eighths inch gypsum board. The wall cavity is filled with thermal insulation. A vapor barrier is applied to the data hall side of the wall as required by project conditions. The intersection is referenced for further coordination via plan and section callouts.
Text on the drawing
THERMAL INSULATION METAL STUD (2) LAYERS OF 5/8" GYPSUM BOARD (2) LAYERS OF 5/8" GYPSUM BOARD VAPOR BARRIER ON DATA HALL SIDE OF WALL, AS OCCURS SEE PLAN/SECT XX SEE PLAN/SECT XX (2) LAYERS OF 5/8" GYPSUM BOARD
