A-NWGRK — Plan Detail Room 160

Architectural · A-NWGRK

Plan Detail Room 160

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Gypsum / Drywall Timber / Wood

Elements

Floors / Slabs Partitions Walls

Text on the drawing

D ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS 1/4" 8" ACOUSTIC WALL ASSEMBLY, EXTEND GYPSUM BOARD TO OUTSIDE FACE OF EXTERIOR STUD. 4
